I would like to share the knowledge about how to get the CAL modification in AL.

When we create extensions, we use to download the symbols first. Now, the first thing we have to do is create a new symbol reference from CAL and then download symbols. Once that is completed we will get all modifications like (Fields, Functions… Etc..).

I have created a new field called Customer Info in the Customer Table:

Adding new field in CAL code

Adding new field in CAL code

Let’s see how to do this

  1. We have to set up the BC administration
    • Allowed Extension Target Level is set to Internal.
    • Enable Developer Service Endpoint checkbox is selected.
    • Enable Loading Application Symbol References at Server Startup checkbox is selected.

      Administration Development Tap properties

      Administration Development Tab properties setup

  2. Run the command prompt as administrator
    • Run Cmd as administration

Run Cmd as administration

  1. Change the directory path to BC installation folder
    • Path: “C:\Program Files (x86)\Microsoft Dynamics 365 Business Central\140\RoleTailored Client”

      Change the directory path to BC installation folder

      Change the directory path to BC installation folder

  2. Execute the Below commandExecute the command
    • finsql.exe Command=generatesymbolreference, Database=”<Database Name>”, ServerName=<DatabaseServer Name>
    • Execute the command
  3. When you run the command, it returns an empty command prompt, and it will not display or provide any indication about the status of the run
    • After completed the command
  4. When the process ends, a file named txt is saved to the Dynamics NAV Client connected to BC installation folder BC installation folder: (“C:\Program Files (x86)\Microsoft Dynamics 365 Business Central\140\RoleTailored Client”).
    • navcommandresult file
  5. If the command succeeded, the file will contain text like [0] [01/27/20 06:54 PM] The command completed successfully in ‘177’ seconds.
    • Note:  It will take little time to complete the process.
  6. Once the navcommandresult.txt created, download the symbols in VS code editor. When I tried to add Customer Info field in the customer list page, it successfully added without compilation errors.
    •  AL CodeAL Code
